UGREEN 90805 1×4 HDMI Splitter 4K@30Hz, 1 Input to 4 Output HDMI Switch, 4K UHD Video Distributor for Fire TV, Laptop, PC, Gaming Console, PS5, Xbox, Set-Top Box, Compatible with Windows, Mac, Linux

UGREEN 90805 1×4 HDMI Splitter 4K@30Hz, 1 Input to 4 Output HDMI Switch, 4K UHD Video Distributor for Fire TV, Laptop, PC, Gaming Console, PS5, Xbox, Set-Top Box, Compatible with Windows, Mac, Linux

Need to display the same content on multiple screens at once? The UGREEN 90805 1×4 HDMI Splitter is your simple, reliable solution for duplicating a single HD video source to up to four displays. Whether for business, education, or entertainment, this compact device delivers seamless screen mirroring in brilliant 4K quality.

Effortless Multi-Screen Setup for Any Scenario

First and foremost, this splitter eliminates the complexity of multi-display setups. Whether you’re conducting a training session, showcasing a product demo, or creating a multi-TV video wall in a shop or home, it provides a straightforward way to amplify your visual impact. Essentially, it turns one video source into four, ensuring your audience never misses a detail. Discover our presentation tools.

Immersive 4K Visual Fidelity

Equipped with advanced HDMI 1.4 technology, this splitter supports resolutions up to 4K (3840×2160) at 30Hz, as well as full 1080p. This means you can enjoy ultra-high-definition videos, graphics, and presentations with vibrant colors and sharp clarity on every connected monitor or TV, without quality degradation.

Universal Compatibility and Reliable Performance

Furthermore, the UGREEN splitter boasts broad compatibility with virtually any HDMI-enabled device. From Windows PCs and MacBooks to PlayStation 5, Xbox Series X, and streaming devices, it connects them all to your display array. The sturdy metal casing ensures stable signal transmission and durability, while the plug-and-play operation guarantees a hassle-free experience right out of the box.

Products Specifications:

• Model: UGREEN 90805
• Function: 1 Input to 4 Output HDMI Splitter / Distributor
• HDMI Version: Version 1.4
• Maximum Resolution: 4K Ultra HD @ 30Hz (3840×2160)
• Supported Resolutions: 4K@30Hz, 1080p@60Hz, 1080i, 720p, 576p, 480p
• Input Port: 1 x HDMI Female
• Output Ports: 4 x HDMI Female
• Power Supply: Plug-and-Play (No external power required for most sources. For high-power devices or long cables, a 5V/1A micro-USB power adapter is recommended).
• Compatible Systems: Windows, macOS, Linux, iOS (via HDMI adapters)
• Compatible Devices: Laptops, PCs, Blu-ray Players, PS4/PS5, Xbox, Nintendo Switch, Fire TV, Roku, CCTV DVR, Set-Top Boxes
• Housing: Aluminum Alloy
• Cable Requirement: HDMI cables required (not included).

What’s in the Box?

• 1 x UGREEN 90805 1×4 HDMI Splitter
• 1 x User Manual

10 FAQs:

1. Can I extend my desktop across 4 screens with this splitter?

No, you cannot. This is a splitter (mirroring device), not an extender. It duplicates the same content from one source to all four displays. To extend your desktop across multiple monitors, you need a graphics card with multiple outputs or a different device.

2. Will it work with my PS5 to show the same game on two TVs?

Yes, absolutely. This is a perfect use case. You can connect your PS5 to the splitter’s input and then connect two or more TVs to the outputs to mirror your gameplay on all screens simultaneously.

3. Do I need an external power adapter?

For most devices (like laptops, set-top boxes), it is plug-and-play and does not need external power. However, for devices with a weak HDMI signal or when using very long HDMI cables (over 5 meters), connecting the included Micro-USB port to a 5V/1A charger is recommended for stable performance.

4. What is the maximum supported resolution?

The maximum supported resolution is 4K (3840×2160 pixels) at a refresh rate of 30Hz. It also fully supports 1080p Full HD at 60Hz.

5. Is it compatible with HDCP-protected content (like Netflix, Blu-ray)?

Yes, it supports HDCP 1.4, which means it can pass through protected content from most streaming devices (Fire TV, Roku) and Blu-ray players to your displays.

6. Can I use it with my older 1080p TV and a new 4K monitor together?

Yes, you can. The splitter will output the same signal to all displays. The resolution will be determined by the lowest common resolution among the connected displays and the source output setting. It’s best to set your source device to a resolution all displays support (e.g., 1080p).

7. Does it support audio extraction or pass-through?

It supports audio pass-through. The audio from your source device (like a laptop or game console) will be transmitted to the displays along with the video signal through the HDMI connection.

8. Why is there no video signal on one of my displays?

First, ensure all HDMI cables are securely connected. Second, try powering the splitter by connecting a 5V USB power adapter to its Micro-USB port. Finally, check if your source device’s resolution is supported.

9. What is the warranty for UGREEN products in Pakistan?

All authentic UGREEN products in Pakistan come with an 12-month warranty from the date of purchase.

10. Can I connect a camera for live streaming to multiple monitors?

Yes, if your camera has an HDMI output port, you can connect it to this splitter to send the live feed to up to four monitors or capture cards simultaneously, ideal for event monitoring or multi-angle streaming setups.
